How to Fix “Connection Reset by Peer” in C Sockets

HOW DID WE DISCOVER THE CONNECTION RESET ISSUE IN OUR EDGE GATEWAY?

While working on a distributed logistics tracking system, our engineering team was tasked with deploying lightweight health-check daemons on remote IoT edge gateways. These daemons, written in C for optimal performance on resource-constrained devices, listened for incoming TCP connections. Upon receiving a health check ping, the server would execute a local shell script to gather telemetry data and respond with a simple HTTP-like success message.

During a recent project phase, we realized that our integration tests using `netcat` were intermittently failing. Specifically, as soon as we introduced a standard `popen()` call to trigger the local OS script, the client side would abruptly drop with a `Connection reset by peer` error. Oddly, when the system was tested without the shell execution logic, the connections succeeded flawlessly.

In production environments, unhandled TCP resets can cause load balancers to mark healthy nodes as dead, leading to cascading service degradation. This challenge inspired this article so others can avoid the common pitfalls of mixing blocking process forks with raw socket management. If your team is struggling with low-level systems programming, you might consider extending your capabilities and choose to hire software developer talent with deep C and networking expertise.

WHERE DID THE TCP SOCKET PROBLEM EMERGE IN THE ARCHITECTURE?

The business use case required the edge daemon to validate its operational status by running an external script whenever a monitoring server connected on a specific port. The architecture was deliberately simple: a single-threaded C server utilizing a standard `bind()`, `listen()` and `accept()` loop.

When a client connected, the server grabbed the client’s IP address, constructed a command string using `asprintf()` and executed it via `popen()`. After `pclose()` confirmed the script finished, the server wrote a standard `200 OK` response to the socket and closed the file descriptor.

The issue surfaced exactly at the intersection of network I/O and process execution. The automated monitoring system used standard shell commands like `echo test | nc <ip> <port>` to simulate payloads. While the server successfully sent the HTTP response back to the client, the client’s terminal immediately threw a connection reset, indicating a sudden, violent teardown of the TCP connection rather than a graceful four-way handshake closure.

WHY DID THE SERVER RETURN ‘CONNECTION RESET BY PEER’?

To identify the root cause, we attached a packet analyzer (`tcpdump`) to the edge gateway. We observed that instead of sending a `FIN` packet when the server called `close()`, the kernel was issuing a `RST` (Reset) packet.

We tracked this down to two distinct, yet interacting, architectural oversights:

• Unread Data in the Receive Buffer: According to TCP RFC specifications, if a process closes a socket that still has unread data in its receive buffer, the TCP stack assumes data loss. To warn the peer that its sent data was never processed, the kernel aborts the connection and sends an `RST`. When we tested with `echo test | nc`, `netcat` transmitted the string “testn”. Our C server never called `read()` or `recv()` on the client socket. It only wrote to it. When `close()` was called, the unread “testn” forced the kernel to send a reset.
• The popen() Timing Delay: Why did the error disappear when we removed `popen()`? It came down to a race condition. Without `popen()`, the server executed `write()` and `close()` in microseconds. The server closed the connection before the client’s “testn” payload even arrived at the server’s network interface. Because the buffer was empty at the exact moment of closure, a normal `FIN` was sent. By adding `popen()`, we introduced a delay (blocking until the script finished), guaranteeing that the client’s payload arrived and sat in the buffer before `close()` was invoked.
• File Descriptor Leakage: `popen()` works by forking the current process. By default, a child process inherits all open file descriptors from its parent. This meant the executing shell script inadvertently held a reference to the active `client_fd`.

When you hire C developers for system-level programming, ensuring they understand these underlying TCP mechanics is critical for building robust services.

WHAT WERE OUR DIAGNOSTIC STEPS AND ALTERNATIVE SOLUTIONS?

We recognized that simply removing `popen()` wasn’t an option, as the business logic required executing the script. We evaluated several approaches to resolve the TCP reset and stabilize the daemon.

HOW DID WE EVALUATE DRAINING THE RECEIVE BUFFER?

The most direct solution to the TCP reset was to read the data from the buffer before closing the socket. By invoking `recv()` with the `MSG_DONTWAIT` flag, we could safely pull any lingering bytes from the kernel queue and discard them. Once the buffer was empty, `close()` would result in a graceful `FIN` packet.

COULD WE AVOID FORKING PROCESSES ENTIRELY?

Calling `popen()` inside a synchronous `accept` loop is generally a poor design choice for high-throughput systems, as it blocks the server from accepting new connections while the script runs. We considered decoupling the execution by writing the IP address to a POSIX message queue or a lightweight message broker, allowing a separate worker process to handle the script execution. However, given the extreme resource constraints of these specific edge devices, introducing a message broker was deemed overkill for this specific project phase.

WHAT ABOUT USING CLOEXEC FLAGS ON SOCKETS?

To solve the file descriptor leakage to the child process, we needed to ensure that any spawned process would not inherit the network sockets. Setting the `FD_CLOEXEC` flag via `fcntl()` on the newly accepted socket guarantees that the file descriptor is automatically closed in the child process when `exec()` is called by `popen()`.

HOW DID WE IMPLEMENT THE FINAL C SERVER FIX?

We refactored the C server code to incorporate buffer draining and file descriptor security. Here is a sanitized version of the implementation we deployed to production:

#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
#include <sys/types.h>
#include <sys/socket.h>
#include <netinet/in.h>
#include <arpa/inet.h>
#include <err.h>
#include <string.h>
#include <fcntl.h>
void set_cloexec(int fd) {
    int flags = fcntl(fd, F_GETFD);
    if (flags != -1) {
        fcntl(fd, F_SETFD, flags | FD_CLOEXEC);
    }
}
void drain_socket(int fd) {
    char buffer[1024];
    // Drain the socket buffer completely to avoid TCP RST on close
    while (recv(fd, buffer, sizeof(buffer), MSG_DONTWAIT) > 0) {
        // Discard data
    }
}
int main() {
    int one = 1, client_fd, sock;
    struct sockaddr_in svr_addr, cli_addr;
    socklen_t sin_len = sizeof(cli_addr);
    sock = socket(AF_INET, SOCK_STREAM, 0);
    if (sock < 0) err(1, "can't open socket");
    // Prevent inheriting the listening socket
    set_cloexec(sock);
    setsockopt(sock, SOL_SOCKET, SO_REUSEADDR, &one, sizeof(int));
    svr_addr.sin_family = AF_INET;
    svr_addr.sin_addr.s_addr = INADDR_ANY;
    svr_addr.sin_port = htons(5050);
    if (bind(sock, (struct sockaddr *) &svr_addr, sizeof(svr_addr)) == -1) {
        close(sock);
        err(1, "Can't bind");
    }
    listen(sock, 5);
    while (1) {
        client_fd = accept(sock, (struct sockaddr *) &cli_addr, &sin_len);
        if (client_fd < 0) continue;
        // Secure FD against popen fork leakage
        set_cloexec(client_fd);
        char iip[INET_ADDRSTRLEN];
        inet_ntop(AF_INET, &cli_addr.sin_addr, iip, INET_ADDRSTRLEN);
        char * ccc;
        if (asprintf(&ccc, "/opt/scripts/status_check.sh %s", iip) != -1) {
            FILE * fff = popen(ccc, "r");
            if (fff) {
                pclose(fff);
            }
            free(ccc);
        }
        const char * response = "HTTP/1.1 200 OKrnrn success rn";
        write(client_fd, response, strlen(response));
        // Drain unread data from 'echo test | nc' before closing
        drain_socket(client_fd);

        close(client_fd);
    }
    return 0;
}

By draining the socket with `recv()` and applying `FD_CLOEXEC`, we entirely eliminated the connection reset errors, resulting in stable, predictable health checks across the edge fleet. If modernizing your legacy edge infrastructure sounds daunting, companies often choose to hire IoT developers for edge computing to manage these low-level implementations safely.

WHAT CAN ENGINEERING TEAMS LEARN FROM THIS SOCKET BEHAVIOR?

Troubleshooting this issue provided several strong reminders about low-level networking design:

• TCP Specifications Rule All: Never assume `close()` guarantees a graceful `FIN`. If there is unread data in the kernel’s receive buffer for that file descriptor, TCP will issue an `RST` to prevent silent data loss.
• Always Drain Before Closing: If your server is designed only to write data (like an information broadcasting port), you must still safely handle and discard incoming bytes from clients to ensure clean connection terminations.
• Beware of Forking Processes: Utilizing `popen()` or `system()` inside a network server is dangerous. Unless `FD_CLOEXEC` is explicitly set, child processes inherit active network sockets, which can lead to bound-port conflicts, security vulnerabilities and unpredictable network behavior.
• Blocking I/O Hurts Scalability: Using `popen()` blocks the main execution thread. While acceptable for a low-traffic edge daemon, enterprise-grade applications require asynchronous task queues. When you hire backend developers for high-performance servers, ensure they default to event-driven paradigms (like `epoll` or `kqueue`) rather than synchronous forks.
• Sanitize Formatted Strings: Building command strings using network-provided data (like an IP address via `asprintf`) requires strict validation to prevent command injection attacks.

HOW CAN YOU APPLY THESE ARCHITECTURAL LESSONS TO YOUR NEXT PROJECT?

Debugging an arbitrary connection reset by peer error often uncovers deeper architectural oversights related to memory management, process forking and TCP specifications. By understanding exactly how the operating system handles socket buffers and file descriptors, you can design vastly more reliable and secure networked applications.

Whether you are building IoT telemetry daemons, migrating legacy C applications or optimizing backend architectures, having a seasoned team makes the difference between resilient platforms and fragile systems. If you need dedicated technical expertise to scale your architecture, contact us to explore how we can support your next critical deployment.
