How to Fix HTTP/2 PROTOCOL_ERROR in AWS NLB & Spring Boot

How Did We Discover the HTTP/2 Protocol Error During a Spring Boot Upgrade?

While working on a high-throughput payment gateway for a FinTech client, our engineering team embarked on a routine technology stack modernization. The goal was to upgrade our core microservices to the latest Spring Boot release to leverage improved performance and security patches. The application was deployed on AWS ECS (Fargate), fronted by an AWS Network Load Balancer (NLB).

During the staging rollout, our automated test suites began failing with a strange anomaly. The deployment succeeded and basic health checks passed over HTTP/1.1. However, our internal microservice-to-microservice communication, which relied heavily on HTTP/2 for multiplexing and low latency, started dropping connections immediately.

It is in moments like these that engineering maturity is truly tested. When companies look to hire software developer teams, they expect proactive debugging of exactly these types of opaque network layer issues. We realized that this failure was tied specifically to how the AWS NLB handled TLS termination and how the upgraded Spring Boot embedded Tomcat container validated incoming protocol streams. This challenge inspired the following technical breakdown so other engineering teams can avoid the same deployment pitfall.

Why Did HTTP/2 Requests Fail While HTTP/1.1 Succeeded in Our FinTech Architecture?

To understand the failure, we must first look at the architectural use case. In our payment routing system, latency is critical. We use an AWS NLB because it operates at Layer 4, providing ultra-low latency and static IP addresses for external vendor whitelisting. To conserve CPU cycles on our Fargate containers, we configured the NLB with a TLS listener. This means the NLB terminates the SSL/TLS connection and forwards plain, unencrypted TCP traffic to the backend target group where our Spring Boot application runs.

Before the framework upgrade, this architecture worked seamlessly. But post-upgrade, the symptoms were highly specific. If we executed a standard curl command over HTTP/1.1, the application responded perfectly:

> curl --http1.1 http://payment-service.internal/actuator/health
{"groups":["liveness","readiness"],"status":"UP"}

However, forcing HTTP/2 prior knowledge resulted in an immediate protocol rejection at the network layer:

> curl --http2 --http2-prior-knowledge http://payment-service.internal/actuator/health
curl: (92) HTTP/2 stream 1 reset by server (error 0x1 PROTOCOL_ERROR)

The business impact of this was significant. Microservices relying on gRPC and HTTP/2 clients were entirely severed from the payment engine, creating a critical bottleneck in the staging environment.

What Caused the HTTP/2 Stream Reset and PROTOCOL_ERROR on AWS NLB?

The most frustrating part of debugging protocol errors is the lack of application-level visibility. We increased the Spring Boot logging verbosity all the way up to TRACE, but the logs revealed absolutely nothing. The requests were being rejected before they even reached the Spring MVC dispatcher servlet.

We began analyzing the OSI model layers. When a client connects to the AWS NLB using HTTPS, they negotiate the protocol using ALPN (Application-Layer Protocol Negotiation). If the client supports HTTP/2, the NLB agrees to use it. However, because we were terminating TLS at the NLB, the NLB then forwarded the raw, decrypted HTTP/2 binary frames over a plain TCP connection to the ECS container.

Sending HTTP/2 over unencrypted TCP is known as h2c (HTTP/2 Cleartext). The root cause lay in the Spring Boot upgrade. The newer version of the embedded Tomcat server introduced stricter compliance with RFC 7540. It no longer silently accepted h2c frames on a standard cleartext port without explicit configuration. Because Tomcat was expecting standard HTTP/1.1 text headers on this unencrypted port, the arrival of binary HTTP/2 frames triggered an immediate parse failure, resulting in the 0x1 PROTOCOL_ERROR.

Which Architectural Approaches Did We Consider to Fix the HTTP/2 Routing?

When you hire backend developers for scalable systems, you expect them to weigh architectural trade-offs rather than just applying the first StackOverflow patch they find. We evaluated several approaches to restore our service communication.

Could We Switch from AWS NLB to Application Load Balancer (ALB)?

An AWS ALB operates at Layer 7 and natively understands HTTP/2. It can terminate the HTTP/2 connection from the client and multiplex it into HTTP/1.1 requests to the backend or route HTTP/2 directly to the backend. However, migrating to an ALB meant losing our static IP addresses, which our external banking partners required for firewall whitelisting. The latency overhead of Layer 7 inspection was also a minor concern. We ruled this out.

Should We Move TLS Termination to the Spring Boot ECS Containers?

If we passed the TCP connection straight through the NLB without terminating TLS, the ALPN negotiation and decryption would happen directly inside the Spring Boot container. Because the connection would be encrypted all the way to Tomcat, standard HTTP/2 (h2) would work natively. The downside was the operational complexity of managing certificate rotation inside ephemeral Fargate containers and the additional CPU overhead for decryption. We opted against this to maintain our clean infrastructure-as-code separation.

Can We Enable HTTP/2 Cleartext (h2c) Prior Knowledge in Spring Boot?

The most robust solution was to explicitly configure our upgraded Spring Boot application to expect and accept h2c traffic on its listener port. By instructing the embedded Tomcat server that the upstream proxy has already handled TLS and that incoming cleartext traffic might be in HTTP/2 binary format, we could restore functionality without changing our infrastructure. This was the path we chose.

How Did We Configure Spring Boot and AWS ECS to Accept h2c Traffic?

To implement the fix, we needed to inject an HTTP/2 upgrade protocol handler into the embedded Tomcat configuration. For organizations looking to hire java developers for enterprise modernization, understanding container-level customizations is a critical skill.

We created a configuration class that customized the Tomcat server factory. This instructs Tomcat to accept cleartext HTTP/2 frames directly without requiring a protocol upgrade handshake.

import org.apache.catalina.connector.Connector;
import org.apache.coyote.http2.Http2Protocol;
import org.springframework.boot.web.embedded.tomcat.TomcatServletWebServerFactory;
import org.springframework.boot.web.server.WebServerFactoryCustomizer;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
@Configuration
public class TomcatHttp2Configuration {
    @Bean
    public WebServerFactoryCustomizer<TomcatServletWebServerFactory> tomcatCustomizer() {
        return factory -> factory.addConnectorCustomizers((Connector connector) -> {
            connector.addUpgradeProtocol(new Http2Protocol());
        });
    }
}

Additionally, we ensured our application properties reflected the correct proxy settings, since the NLB was acting as a reverse proxy:

server.http2.enabled=true
server.forward-headers-strategy=framework

After deploying this configuration to our AWS ECS cluster, we validated the fix. Rerunning the diagnostic curl command with prior knowledge yielded the expected result:

> curl --http2 --http2-prior-knowledge http://payment-service.internal/actuator/health
{"groups":["liveness","readiness"],"status":"UP"}

The network layer correctly parsed the binary frames, our internal microservices reconnected and the payment platform stabilized.

What Can Engineering Teams Learn From This AWS NLB and HTTP/2 Mismatch?

When tech leaders hire cloud developers for production deployment, they rely on those teams to abstract away infrastructure complexities. This specific integration issue highlights several broader lessons for enterprise engineering teams:

• Layer 4 vs Layer 7 Load Balancing: Always remember that an NLB (Layer 4) with a TLS listener decrypts traffic but does not translate the application-layer protocol. If the client negotiates HTTP/2, your backend must be ready to receive raw HTTP/2 frames.
• Framework Upgrades Enforce Strictness: Major version bumps in frameworks like Spring Boot often update embedded servers (Tomcat, Jetty, Undertow) to strictly enforce RFC standards. Silent fallback mechanisms are frequently removed for security reasons.
• Logs Have Limits: If a request is malformed at the network protocol layer (like sending binary frames to a text-expecting socket), application-level loggers will not catch it. You must rely on network analysis tools or understand the ingress architecture.
• h2c is for Internal Networks Only: HTTP/2 cleartext (h2c) should only be used behind a secure boundary (like an AWS VPC). Never expose h2c directly to the public internet without a load balancer terminating TLS first.
• Prior Knowledge is Crucial: HTTP/2 over cleartext can happen via an HTTP/1.1 upgrade header or via “prior knowledge” where the client just starts sending binary frames. AWS NLB passes through prior knowledge streams, so the backend must be explicitly configured to handle them.

How Does Resolving Protocol Errors Enhance Microservice Reliability?

Tracking down a curl error 92 PROTOCOL_ERROR in a modernized cloud environment requires looking beyond application code and understanding the intricate dance between cloud load balancers and containerized runtimes. By correctly mapping our AWS NLB TLS termination to Spring Boot’s h2c capabilities, we preserved our low-latency architecture while benefiting from the framework upgrade. If your organization is scaling its infrastructure and you need a dedicated engineering team capable of solving deep architectural challenges, contact us.
